Disc Mower - Front SC - 301 / SC – 301C / SC - 301R

Working width 3,01 m
Excellent cutting quality
Cutterbar attached on both sides forms a rigid unit with frame
Soles made from Hardox material
Low-maintenance oil filled gearbox in the cutterbar
Cutterbar flotation using springs
Overrunning friction clutch on the PTO drive shaft protecting against overload
Transverse copying of the cutter bar
Optional accessories: additional hardox soles +20 and +50, extension of camping triange for the 3point hitch on tractors, for SC-301C - extended version of the dropping plates for a single swath line cutting with 1,5 m width

Technical data		SC - 301	SC - 301C	SC - 301R
conditioner / type		no	yes / finger	yes / roller
working width	m	3,01	3,01	3,01
transport width	m	2,88	2,88	2,88
transport height	m	1,74	1,74	1,74
number of disc	pcs	7	7	7
numer of knives on disc	pcs	2	2	2
knife size	mm	110x50x4	110x50x4	110x50x4
stubble height	mm	40-80	40-80	40-80
area capacity	ha / hour	3,3	3,3	3,3
minimum drive power of the tractor	kW	60	70	70
drive shaft speed	rpm	1000	1000	1000
weight	kg	752	954	1097
cardan shaft type		AW21101 F750Nm	AW21101 F750Nm	AW21101 F750Nm
